TOOL PURPOSE
Track Saws allow you to easily make miter cuts and rough cuts on large sheets of material. Refer to the following
diagrams to become familiarized with all the parts and controls of your track saw. The components will be referred
to later in the manual for assembly and operation instructions.
KNOW YOUR TRACK SAW
11
1
2
3
6
4
5
7
8
9
11
12
13
14
1. Front Grip
2. Depth Scale
3. Bevel Scale
4. Track Compensation
5. Depth Adjustment Knob
6. Front Bevel Lock Knob
7. Front Fine Adjustment Knob
8. Track Lock
9. Plunge Lock Button
10. Dust Port
11. Power Trigger
12. Speed Adjustment Wheel
13. Rear Bevel Lock Knob
14. Rear Fine Adjustment Knob
15. Base Plate
15
10
