3
SPECIFICATIONS
Model Number DF680iX
Surge (Starting) Wattage
Gasoline: 6800W
LPG: 6000W
Rated (Running) Watt-
age
Gasoline: 5100W
LPG: 4500W
Rated Voltage AC: 120V / 240V; DC: 12V / 5V
Rated Amperage
120V AC: 42.5A Gas, 37.5A LPG. 240V AC: 21.25A Gas, 18.75A LPG.
DC: 8A (12V), 2.1A / 1A (USB)
Phase Single
Frequency 60 Hz
Product Weight 94.8 lbs
Product Dimensions 22.8 in. x 16.6 in. x 19.7 in.
GENERATOR
Engine Type 4 Stroke, OHV, Single Cylinder with Forced Air Cooling System
Engine Displacement 224cc
Engine Speed 4500 RPM
Fuel Tank Capacity 2.9 Gallons (11 L)
Oil Capacity 26.37 fl. oz. (0.78 L)
Half-Load Run Time
Gasoline: 6.1 Hours
LPG: 9 Hours
Spark Plug Type LG F6RTC (NGK BPR6ES)
Spark Plug Gap 0.024 - 0.031 in. (0.6 - 0.8 mm)
Spark Plug Torque 11 - 14.75 ft-lb (15 - 20 Nm)
Battery 12V, 7Ah, Lead-Acid
ENGINE
