NO. PART NO. DESCRIPTION QTY.
1 DF500iX-001 Screw, M5x10 6
2 DF680iX-002
Control Panel
Assembly
1
3 DF500iX-010
Self-tapping Screw,
ST3.5x13
1
4 DF500iX-011 Washer, 4mm 1
5 DF500iX-012 Igniter 1
6 DF500iX-003 Step Bolt, M6x15 24
7 DF480iX-090
LPG Quick-connector
Cap
1
8 DF500iX-008 Front Cover Plug 3
9 DF500iX-004 Front Cover 1
10 DF500iX-037 Clip 4
11 56360iX-108 Wiring Sheath, 25mm 2
12 DF680iX-036
Display Multimeter
Wiring Harness
1
13 DF680iX-033 Inverter 1
14 56202i-051 Bolt, M6x12 9
15 DF680iX-015 Clamp 1 1
16 DF680iX-016 Clamp 2 1
17 DF500iX-017 Left Panel Assembly 1
18 DF500iX-046 Stepped Bolt, M6x17 6
19 DF500iX-016 Left Housing 1
20 DF680iX-020 Screw, M4x8 1
21 DF680iX-021 Nut, M4 1
22
DF680iX-
022ASM
Engine Assembly 1
23 DF500iX-019 Fuel Tank Cap 1
24 DF500iX-020 Fuel Tank Seal 1
25 DF500iX-026 Bolt, M6x25 4
26 DF500iX-027
Washer,
6.5x1.5x25mm
10
27 DF500iX-022 Drawbar Pin 2
28 DF500iX-023
Upper Housing
Assembly
1
29 DF500iX-024
Upper Handle
Assembly
1
30 DF500iX-030 Spacer 2
NO. PART NO. DESCRIPTION QTY.
31 DF500iX-025
Handle Connecting
Bolt
2
32 DF500iX-021 Adjustable Handle 1
33 DF500iX-038 Fuel Hose Jacket 1
34 DF500iX-034 Fuel Hose 1
35 DF500iX-032 Fuel Tank 1
36 DF500iX-035 Clamp 1
37 DF500iX-029 Fuel Hose 1
38 DF500iX-018 Nut, M6 6
39 DF500iX-042 Rear Cover Gasket 1
40 DF500iX-040 Rear Cover 1
41 DF500iX-028 Clamp 1
42 DF500iX-048
Fuel Valve and
Selector Switch
1
43 DF500iX-049 Right Housing 1
44 56477i-025 Bolt, M5x12 3
45 DF680iX-043
Remote Start Engine
Control Module
1
46 DF480iX-076
Self-tapping Screw,
ST4.2x16
2
47 DF500iX-052
Sound Insulation Pad
1
2
48 DF500iX-014
Sound Insulation Pad
2
1
49 DF475-041
Battery, 12V 7Ah,
Lead-acid
1
50 DF500iX-051 Tape 1
51 DF500iX-050
Battery Wiring
Harness
1
52 DF500iX-054 Right Panel Assembly 1
53 56202i-001 Phillips Screw, M4x10 1
54 DF500iX-013
Handle Protection
Plate
1
55 DF500iX-045 Bolt, M8x16 2
56 DF500iX-056 Engine Mount 1 1
57 DF500iX-057 Engine Mount 2 1
58 DF500iX-058 Engine Mount 3 2
59 DF500iX-059 Nut, M8 10
60 56477i-018 Bolt, M8x12 2
EXPLODED VIEW & PARTS LIST
GENERATOR
37
