NO. PART NO. DESCRIPTION QTY.
65 GN9500-165 Dipstick Assembly 1
66 GN9500-166 Dipstick 1
67 GN9500-167 Dipstick O-ring 1
68 GN9500-168 Governor Gear 1
69 GN9500-169 Ball Bearing, 6202 2
70 GN9500-170 Balance Shaft 1
71 GN9500-171
Starter Motor
Assembly
1
72 GN9500-172 Crankcase 1
73 GN9500-173 Governor Gear Shaft 1
74 GN9500-174 Washer 1
75 GN9500-175 Oil Seal, Governor 1
76 GN9500-176 Cotter Pin 1
77 GN9500-177 Governor Arm 1
78 GN9500-178X
Fuel Hose
(Ø4xØ10x190)
1
79 GN9500-179X Clamp 1
80 GN9500-180 Governor Spring 1
81 GN9500-181 Governor Rod 1
82 GN9500-182 Idler Spring 1
83 GN9500-183 Clip 1
84 GN9500-184 Bolt, M6x10 1
EXPLODED VIEW & PARTS LIST
ENGINE
NO. PART NO. DESCRIPTION QTY.
85 GN9500-185 Washer 2
86 GN9500-186
Oil Drain Bolt,
M12-1.5x15
2
87 GN9500-187 Bolt, M8x35 2
88 GN9500-188 Ignition Coil Plate 1
89 GN9500-189 Bolt, M6x8 1
90 GN9500-190 Bushing 1
91 GN9500-191 Charging Coil 1
92 GN9500-192 Bolt, M6x28 4
93 GN9500X-193 Ignition Coil 1
94 GN9500-194 Clip 1
95 GN9500-195 Oil Seal, Flywheel 1
96 GN9500-196 Flywheel 1
97 GN9500-197 Fan 1
98 GN9500-198 Starter Cup 1
99 GN9500-199 Nut, M16-1.5 1
100 GN9500-200
Recoil Starter
Assembly
1
101 GN9500-201 Recoil Starter Housing 1
102 GN9500-202 Recoil Starter 1
103 GN9500-203 Washer 3
104 GN9500-204 Bolt, M6x10 3
105 GN9500-026 Air Filter Bracket 1
42
