Wen GN9500X User Manual

EXPLODED VIEW & PARTS LIST
NO. PART NO. DESCRIPTION QTY.
1 GN9500-101 Bolt, M6x16 7
2 GN9500-102 Cylinder Head Cover 1
3 GN9500X-103 Breather Tube 1
4 GN9500-104
Gasket, Cylinder Head
Cover
1
5 GN9500-105 Rocker Arm Assembly 2
6 GN9500-106 Rocker Arm Base 1
7 GN9500-107 Valve Locking Clip 4
8 GN9500-108
Valve Adjustment Cap,
Exhaust
2
9 GN9500-109
Valve Spring Seat,
Upper
2
10 GN9500-110 Valve Spring Seat 2
11 GN9500-111 Intake Valve Seal 1
12 GN9500-112
Valve Spring Seat,
Lower
2
13 GN9500-113 Bolt, M10-1.25x87 4
14 GN9500-114 Cylinder Head 1
15 56500-123
Spark Plug (Torch
F6TC/NGK BP6ES)
1
16 GN9500-116 Stud, M8x35 2
17 GN9500-117 Gasket, Exhaust Tube 1
18 GN9500-118 Exhaust Tube 1
19 GN9500-119 Nut, M8 2
20 GN9500-120 Shroud 1
21 GN9500-121 Stud, M6-0.8x110 2
22 GN9500-122
Gasket, Carburetor
Insulator
1
23 GN9500-123 Insulator 1
24 GN9500-124 Gasket, Carburetor 1
25 GN9500-125 Carburetor 1
26 GN9500-126 Gasket, Air Filter 2
27 GN9500-127 Stepper Motor Bracket 1
28 GN9500-128
Auto-Choke Stepper
Motor
1
29 GN9500-129 Stepper Motor Cover 1
30 GN9500-130 Screw, M4x8 2
31 GN9500-131 Spring 1
ENGINE
NO. PART NO. DESCRIPTION QTY.
32 GN9500-132 Guide Clamp 1
33 GN9500-133 Air Filter Assembly 1
34 GN9500-134 Air Filter Clip 2
35 GN9500-135 Air Filter Housing 1
36 GN9500-136
Gasket, Air Filter
Housing
1
37 GN9500-137 Air Filter Baffle 1
38 GN9500-138
Air Filter Elements
(Coarse & Fine)
1
39 GN9500-139 Air Filter Cover 1
40 GN9500-140 Nut, M6 3
41 GN9500-141 Gasket, Cylinder Head 1
42 GN9500-142 Pin, Ø12x20 2
43 GN9500-143 Push Rod 2
44 GN9500-144 Tappet 2
45 GN9500-145 Exhaust Valve 1
46 GN9500-146 Intake Valve 1
47 GN9500-147 Piston Ring Set 1
48 GN9500-148 Circlip 2
49 GN9500-149 Piston Pin 1
50 GN9500-150 Piston 1
51 GN9500-151
Connecting Rod As-
sembly
1
52 GN9500-152
Governor Gear Bracket
Assembly
1
53 GN9500-153 Bolt, M6x12 8
54 GN9500-154 Oil Sensor 1
55 GN9500-155 Ball Bearing, TM6207 1
56 GN9500-156 Crankshaft 1
57 GN9500-157 Woodruff Key 1
58 GN9500-158 Camshaft 1
59 GN9500-159 Washer 1
60 GN9500-160 Pin, Ø8x12 2
61 GN9500-161 Gasket, Crankcase 1
62 GN9500-162 Crankcase Cover 1
63 GN9500-163 Oil Seal, Alternator 1
64 GN9500-164 Bolt, M8x38 7
41
