To adjust the dust skirt:
1. Pull one end of the skirt off of the machine until you reach the middle of the
skirt.
2. Position the skirt until it is barely touching the ground and repeat with the other
end.
Avoid positioning the dust skirt too low as it will drag against the ground, wearing
the skirt out prematurely and possibly preventing smooth machine movement.
!
To adjust the handle:
3. The handle on the TITAN XT is spring-loaded, pop the pin and adjust the
handle to the desired operating position.
4. On the COLOSSOS XT, pull the pin and adjust the handle to the desired
operating position.
!!
!
!
Failure to check the handle is fully engaged could result in damage to the
machine or personal injury as the handle could release unexpectedly when the
machine is being operated or tilted back.
!
!
!
When the machine is first plugged in, the following start-up screen will appear
showing the model of the VFD and the software version.
!
!
!
After the machine runs through its initial start-up sequence, the screen will show
the VFD status, pad driver speed in revolutions per minute (RPM), and percent of
motor load.
!
