ITEM
QTY
PART NUMBER
DESCRIPTION TITAN XT
!
!
!
!
1
1
110-0088-00
Vacuum Tube Assembly
2
1
100-0631-00
Cover
3
1
100-0625-00
Drive Train, Lower Plate
4
17
500-0013-00
Bearing
5
8
550-0022-00
Key
6
8
500-0254-00
Sprocket
7
8
500-0255-00
Bushing
8
7
100-0578-01
Drive, Short Shaft
9
1
550-0007-00
Key Stock
10
1
500-0248-00
Bushing
11
1
500-0252-00
Sprocket
12
1
100-0577-03
Drive, Long Shaft
13
1
500-0256-00
Sprocket
14
2
500-0006-00
Bearing
15
1
100-0628-00
Idler Shaft Spacer
16
1
100-0627-00
Offset Idler Shaft
17
1
520-0041-00
Belt
18
1
100-0626-00
Drive Train, Upper Plate
19
1
100-0585-01
Bearing Plate
20
8
100-0629-00
Drive Train Spacer
21
8
590-0120-00
Fastener
22
1
100-0651-00
Idler Wrench
23
1
590-0245-00
Fastener
24
3
590-0169-00
Fastener
25
1
008-0343-00
Weather Strip
26
1
590-0260-00
Fastener
27
1
590-0261-00
Lock Nut
28
9
590-0142-00
Lock Washer
29
1
100-0635-00
Belt Check Mounting Plate
30
9
590-0114-00
Fastener
31
8
590-0124-00
Fastener
32
4
540-0151-00
Vibration Dampener
33
1
540-0133-00
VFD
34
2
540-0156-00
Strain Relief
35
1
540-0072-00
Strain Relief
36
2
590-0047-00
Washers
37
1
540-0073-00
Strain Relief
38
1
540-0002-00
Mating Receptacle
39
1
540-0068-00
Strain Relief
40
1
540-0069-00
Strain Relief
41
1
540-0218-00
Conduit
42
1
540-0008-00
Cable
43
1
540-0268-00
Cable Retainer
44
1
540-0060-00
Plug
45
1
520-0042-00
Belt
46
1
530-0005-00
Motor
47
1
550-0021-00
Key Stock
48
1
500-0066-00
Bushing
49
1
500-0253-00
Sprocket
50
1
120-0002-02
Motor Shroud Assembly
51
7
590-0115-00
Fastener
52
1
130-0091-00
Handle
53
1
130-0093-00
Handle Assembly
54
1
540-0005-00
Start Button
55
1
540-0006-00
Stop Button
56
4
540-0179-00
Threaded Bumper
57
1
540-0117-00
Potentiometer
58
1
540-0116-00
Potentiometer
59
2
580-0122-00
Handle Grip
60
1
580-0089-00
T-Handle Assembly
