7
2. Slide the two Wheel Housings (62) onto the Base (52),
with the heads of the M10 x 62mm Bolts (35) facing out-
ward as shown. Attach each Wheel Housing with two M6
x 58mm Bolts (6), two M6 Washers (11), and two M6
Nuts (15).
2
52
6
11
62
15
11
6
62
35
35
15
1. Have a second person hold the Base (52) in the position
shown.
I
dentify the Left Upright (53) (the Right Upright [54] has a
large hole near the lower end).
Hold the Left Upright (53) so that the bend is in the
position shown. Insert two M10 x 58mm Bolts (2) into
the bracket on the Left Upright. Then, attach the Left
Upright to the Base (52) with the Bolts, two M10 Washers
(14), and two M10 Nuts (16). Do not tighten the Nuts
yet.
Attach the Right Upright (54) to the Base (52) in the
same way.
52
53
54
1
16
14
14
2
Large
Hole
Bend
