MAINTENANCE
Hose Routing for MVP PLUS™ Blades
To PS Rod
(Front)
To DS Base
(Rear)
To PS Base
(Rear)
To Lif t Ram
To DS Rod
(Front)
Hose Routing for Straight Blades
Driver-Side
Hose
Passenger-Side
Hose
Lift Ram
Hose
