Note - Output capacity depends on installation and operating conditions.
Whale's policy is one of continuous improvement and we reserve the right to change
specifications without prior notice.
2. SPECIFICATION
Model Bilge IC bilge water kit
Product Code BP2083B SI8284 SI8222B SI8224B BP2085B SI8484 SI8422B SI8424B
Cable Length /
4m
(12ft)
2m
(6ft)
4m
(12ft)
/
4m
(12ft)
2m
(6ft)
4m
(12ft)
Voltage
12V d.c. 24V d.c.
Voltage Range 10 v d.c. to 13.6 V d.c. 21.6 V d.c. to 27.2 V d.c
Current Profile Soft start / soft stop
Recommenced Fuse
Size
10 Amp Automotive 5 Amp Automotive
Minimum Wire Size
1.5mm² (16 AWG)
Weight 2.6 kg (5.7 lbs)
Materials
Pump head - Glass filled Nylon. Valves and Diaphragm - Santoprene®
Pump Body - Aluminium. Gear Wheel - Delrin®
Fasteners - Stainless Steel
Service Kits /
Accessories
AK2050 - Replacement Gulper® Pump Head
AK2086B - Deutsch Connector Extension Cable 6m (18ft)
Hose Connections
Gulper® IC - Barbed connections - either 19mm (¾") or 25mm (1")
Strainer IC - 19mm (3/4") port
Port Orientation for
Strainer IC
Horizontal (easily changed to vertical / side)
Maximum Suction Lift
(Vertical)
3m (10 ft)
Maximum Discharge
Head (Vertical)
3m (10 ft)
Maximum Discharge
Head and Suction Lift
Combined (vertical vent)
4m (13.5 ft)
Operational Time
Delays
1 second on delay / 45 second off delay
Current Draw On
Standby
Low power 0.01 Amps supply
PERFORMANCE DATA
Suction Lift 0m / 0ft 0m / 0ft 1m / 3ft 1m / 3ft
Discharge Head 1m / 3ft 1m / 3ft 1m / 3ft 1m / 3ft
Hose Size 19mm / ¾" 25mm/ 1" 19mm / ¾" 25mm/ 1"
Flow Rate per min
19 ltrs
(5 US gals)
17.5 ltrs
(4.6 US gals)
17.5 ltrs
(4.6 US gals)
15.5 ltrs
(4.1 US gals)
Flow Rate per hour
1140 ltrs
(300 US gals)
1050 ltrs
(276 US gals)
1038 ltrs
(270 US gals)
930 Ltrs
(246 US gals)
Current Draw (12 V d.c.) 7.5 amps 8 amps 7.5 amps 8 amps
Current Draw (24 V d.c.) 3.25 amps 4 amps 3.25 amps 4 amps
