1. TYPICAL INSTALLATION 12. PLUMBING
2. SPECIFICATION 13. INSTRUCTIONS FOR USE
3. CONTENTS AND DIAGRAMS 14. MAINTENANCE
4. PRINCIPLES OF OPERATION 15. HELPFUL HINTS
5. TO THE USER 16. TROUBLE SHOOTING
6. TO THE FITTER 17. WINTERIZING
7. APPLICATION 18. SERVICE SUPPORT DETAILS
8. WARNINGS 19. PATENTS/ TRADEMARKS
9. PARTS LIST 20. WARRANTY STATEMENT
10. OPTIONAL EXTRAS 21. EU DECLARATION OF
11. INSTALLATION CONFORMITY, APPROVALS
LIST OF DIAGRAMS:
FIG 1 GULPER® IC - TYPICAL INSTALLATION AS A REMOTE MOUNTING
BILGE PUMP FOR USE WITH WHALE STRAINER IC
FIG 2 PUMP ORIENTATION
FIG 3 GULPER® IC INSTALLATION
FIG 4 INSTALL P CLAMP
FIG 5 STRAINER IC CONNECTION
FIG 6 STRAINER IC CONNECTION
FIG 7 WIRING GULPER® IC TO STRAINER IC
FIG 8 CONNECTING SWITCHING CABLE THROUGH BULKHEAD
FIG 9 CONNECT DEUTSCH® CONNECTORS
FIG 10 SECURING PIPEWORK
FIG 11 STRAINER IC OPERATION TEST
FIG 12 FOR CLEANING - DETACH TOP COVER OF STRAINER IC
FIG 13 FOR CLEANING - UNSCREW VALVE HOUSING
IC - Intelligent Control Technology
At the heart of every Whale® IC product lies innovative electronic control circuitry built
in. This enables IC sensor accessories to communicate directly with IC pumps to
control their performance. These accessories send signals to built-in intelligent
software which then control the pumps to react as required.
Gulper® IC
The Gulper® IC fully automatic self-priming pump is designed as a remote mounting
bilge pump. Output capacity depends on installation and operating conditions.
REMOTE MOUNTED BILGE APPLICATION
Save time and money by reducing four separate components to one pre-wired
system. Remote mounting automatic Gulper® IC receives signals from Strainer IC
3. LIST OF CONTENTS AND LIST OF DIAGRAMS
4. PRINCIPALS OF OPERATION
