Suggested wiring information is given as a guide only. For full information, refer to the
USCG, ABYC and ISO regulations for marine applications and wiring gauges,
connectors and fuse protection.
Contact Whale® Support team for further technical advice +44 (0)2891 270531 or
email: info@whalepumps.com
Qty 1 Gulper® IC bilge pump Qty 1 Strainer IC
Qty 3 No.8 self tappers and washers Qty 1 Inline fuse assembly
AK2050 - Service kit - Replacement head for all Gulper® pumps
AK2086B - Deutsch® Connector Extension Cable 6m (18ft)
NOTE: Incorrect installation will invalidate warranty
Preparation - Always disconnect power sources before installing.
11.i Location
Choose a position to mount the pump that is dry and away from standing
water and is free from obstacles.
Mount in a position with the shortest possible pipe run lengths.
11.ii Mounting Instructions - Gulper® IC
Gulper® IC can be mounted on a horizontal or vertical surface.
When mounted vertically ensure that the pump head is lower most (see
Fig 2).
NOTE -It is recommended that the outlet is mounted above the water line and anti-
syphon loops are fitted where applicable- see typical installation (Fig. 1)
When mounting, position the pump on surface and work out the best
angles for the hose (to prevent kinking) and mark the 3 hole positions
using the pump feet.
NOTE: The pump head may be rotated to suit the hose connections.
9. PARTS LIST
10. OPTIONAL EXTRAS
11. INSTALLATION
Fig. 2 - Pump Orientation
