• Mark the hole centres through unit backplate.
• Drill holes in wall and fit wall plugs (if necessary).
Use 6mm masonry bit.
• Secure the backplate to the wall using
supplied screws.
• Use screw locations 1,2,3. Locations A and B
are optional.
3. Mounting your pump to the wall
• Push the pipes into the fittings to the full depth of
insertion and secure by locking the fittings using
the "twist lock".
4. Plumbing connections
