Step 12 Electrical Connections 12V d.c.
Vehicle Manufacturer Installation - Part Number: SH2211 or SC2211
WARNING: Always disconnect the appliance from the power supply prior to working on electrical components.
The Space Heater and Control Panel come complete with electrical connectors fitted. The Whale® Space Heater and
Control Panel are designed to be integrated into the caravan’s wiring loom. The Space Heater is provided with a JST
VL series 12 way socket, and the Control Panel with JST VL 6 and 3 way sockets. 9 wires are required to connect
the Space Heater to the Control Panel. The 12V d.c. power supply (red wire) and 0V d.c. power supply (white wire)
are to be connected to the 12 way socket at the Space Heater (as shown in Table 1 and 2). Please note: Whale
recommends that a 5 amp automotive fuse is fitted in the 12V d.c. supply.
Table 1: Connections at Space Heater
Table 2: Connections at Control Panel
Retail Installation - Part Number: SH2201 or SH2202
The Space Heater and Control Panel come with electrical connectors fitted.
Step 1
Connect the 12 way electrical connector with the unattached red and white leads to the 12 way connector on the
Space Heater.
Step 2
Route the wire to the Control Panel and connect the 6 way electrical connector to the 6 way connector on the Space
Heater.
Step 3
Route the 3 way electrical connector to the 3 way connector at the Control Panel.
Step 4
Secure the wire close to the Control Panel ensuring that there is no strain on the wires at the switches.
Step 5
Connect the free red lead coming from the 12 way connector to a 12V d.c. supply.
Connect the free white lead to the caravan 0V d.c. supply.
Please note: Whale recommends that a 5 amp automotive fuse is fitted in the 12V d.c. supply.
17
Terminal Number Description Wire Colour
1 Switch common Brown
2 0V to Switch panel Black
3 Fan Switch Yellow
4 Electric 1 Switch Green
5 Electric 2 Switch Grey
6 Electric 3 Switch Pink
7 Burner Switch Blue
8 Burner LED Orange
9 Lockout LED Violet
10 12V supply Red
11 0V supply White
Connector
Terminal
Number
Description Wire Colour
6 Way
connector
1 Switch common Brown
2 Burner Switch Blue
3 Fan Switch Yellow
4 0V to Switch panel Black
5 Burner LED Orange
6 Lockout LED Violet
3 Way
connector
1 Electric 1 Switch Green
2 Electric 2 Switch Grey
3 Electric 3 Switch Pink
