6
DIMENSIONS
Internal installation - SH2201 or SC2201
Fig. 4 Internal Installation - Side View - SH2201 / SC2201
Fig. 6 Internal Installation - Front View - SH2201 / SC2201
Cold Air Inlet
Hot Air Outlet
Exhaust Flue
Combustion Air Inlet
Space Heater
Gas In
270mm
257mm
226mm
Cold Air Inlet
Exhaust Flue
Combustion Air Inlet
Cold Air Inlet
Hot Air Outlet
157mm
78mm
46mm
Reset Button
Reset Button (Red)
610mm
634mm
121mm
137mm
141mm
Fig. 5 Internal Installation - Plan View - SH2201 / SC2201
