Whale SH2201 - Page 8

DIMENSIONS
External (underfloor) installation - SH2211 or SC2211
Fig. 10 External (Underfloor) Installation - Plan View - SH2211 / SC2211
Fig. 11 External (Underfloor) Installation - Side View - SH2211 / SC2211
Fig. 12 External (Underfloor) Installation - Front View - SH2211 / SC2211
8
Cold Air Inlet
Hot Air Outlet
Exhaust Flue
Combustion Air Inlet
Gas In
531mm
180mm
171mm
76mm
121mm
Exhaust Flue
Combustion Air Inlet
Hot Air Outlet
25mm
65mm
Exhaust Flue
Combustion Air Inlet
Hot Air Outlet
Cold Air Inlet
226mm
261mm
288mm
Reset Button
