Dimensions
A = 825 mm
B = 560 mm
C = 595 mm
Weight = 30 kg
Remove the transport packaging and the tape before starting dryer.
Packing accessories
Check list of the accessories and materials provided with the machine:
To ensure the dryer operates normally, please ensure the following:
• The rear of the dryer must not have any restriction to the intake of fresh air.
• Check whether there is any damage to the dryer during transportation.
Any damaged dryer must not be connected. In case of any damage, contact your supplier.
• The surrounding environment must be dry and ventilated
• To allow the dryer to perform better, the ambient temperature shall neither be lower than 10°C nor higher
than 35°C.
FREESTANDING INSTRUCTIONS
• The dryer must be kept away from flammable substances
Name Operation
manual
Wall
mounting kit
Panel film Drying rack Retaining
clip
Warranty
Card
Quantity 1 1 1 1 2 1
A
C
B
5
TumbleDryer_AWD60A-4.indd 5 5/8/08 4:25:45 PM
INSTALLATION
