FOR SERVICE TECHNICIAN’S USE ONLY
DO NOT REMOVE OR DESTROY
MANUAL OVERVIEW TEST MODE — See page 4 to access Manual Overview Test Mode. = ON
Pressing the START button will activate/deactivate each output. When the output is activated, the corresponding Status LEDs
will flash. IMPORTANT: Lid must be closed and locked to perform SPIN & AGITATE tests.
48
1
8
2
8
18
8
UNUSED
4
4 2
4 1
4
UNUSED
21
UNUSED
UNUSED
UNUSED
OUTPUT
Output Details
NOTE: Outputs will time-out after 5 minutes.
SOAK/
WASH
RINSE
FINAL
SPIN
DONE
LID
LOCKED
LID LOCK
COLD VALVE
1
HOT VALVE
2
DRAIN
LOW SPIN – To perform test, lid must be closed and locked.
On
HIGH SPIN – To perform test, lid must be closed and locked.
On
GENTLE AGITATION – To perform test, lid must be closed and locked.
HEAVY AGITATION – To perform test, lid must be closed and locked.
Shifts from idle motor to heavy CW/CCW agitation. NOTE: Allow up to 15 seconds for shifter to reposition.
IMPORTANT: To activate Heavy Agitation, RPM must read “0” and lid must be closed with lid lock enabled. If lid is not closed,
status LEDs will flash on and off.
• If motor does not agitate, go to TEST #3a & 3b: Drive System (Shifter & Motor), pages 13 & 14.
STATUS LEDs
Spins basket from 0 to 500 RPM. NOTE: Allow up to 15 seconds for shifter to reposition.
IMPORTANT: To activate Low Spin, RPM must read “0” and lid must be closed with lid lock enabled.
If lid is not closed, status LEDs will flash on and off. IMPORTANT: Water in tub must be drained before test.
• If motor does not spin, go to TEST #3a & 3b: Drive System (Shifter & Motor), pages 13 & 14.
Spins basket from 0 to maximum RPM. NOTE: Allow up to 15 seconds for shifter to reposition.
IMPORTANT: To activate High Spin, RPM must read “0” and lid must be closed with lid lock enabled.
If lid is not closed, status LEDs will flash on and off. IMPORTANT: Water in tub must be drained before test.
• If motor does not spin, go to TEST #3a & 3b: Drive System (Shifter & Motor), pages 13 & 14.
Shifts from idle motor to gentle CW/CCW agitation. NOTE: Allow up to 15 seconds for shifter to reposition.
IMPORTANT: To activate Gentle Agitation, RPM must read “0” and lid must be closed with lid lock enabled. If lid is not closed,
status LEDs will flash on and off.
• If motor does not agitate, go to TEST #3a & 3b: Drive System (Shifter & Motor), pages 13 & 14.
Turns ON and turns OFF the drain pump.
• If pump does not turn on, go to TEST #7: Drain Pump, page 17.
Lock and unlock the lid. NOTES: When lock is enabled, the “Lid Locked” LED will turn ON. Will only lock when lid is closed.
Will only unlock when basket RPM is 0. If lid is not closed, washer will flash status LEDs on and off.
• If lid does not lock or unlock, go to TEST #8: Lid Lock, page 18.
Turns ON and turns OFF cold water valve.
• If valve does not turn on, go to TEST #2: Valves, page 13.
Turns ON and turns OFF hot water valve.
• If valve does not turn on, go to TEST #2: Valves, page 13.
On
On
21
2
