If your current
terminal has the
following letter
Writedown
that letter
here
Labelthewires
with the following
letters
Terminal function
W2** W2
2ndStageHeat(Conventional)2ndStageAuxiliary
Heat(HeatPump)
Y,Y1 Y 1stStageCompressor
Y2 Y2 2ndStagecompressor
G G Fan Relay
O,B*,O/B O/B ReversingValve(forheatpumpsystems)
L L HeatPumpDiagnostic
Terminal labeling reference chart, contʼd.
