Thermostat Terminals
with attached wires
Indoor Equipment Setting (Used in 4.5)
▢
No wire on thermostat terminal W/E
Blower only (no indoor heating
equipment)
FAN
▢
W/E (Gas or Oil heat) Single stage gas or oil furnace GA1
▢
W/E, W2 (Gas or Oil heat) Two stage gas or oil furnace GA2
▢
W/E (Electric heat) Single stage electric furnace EL1
▢
W/E, W2 (Electric heat) Two stage electric furnace EL2
