INSTALLATION INSTRUCTIONS
Location
The air conditioner should be placed on a hard and level surface strong enough to support its weight.
The unit is equipped with caster wheels for portability. It should only be rolled on smooth, flat
surfaces. Use caution when rolling on carpet surfaces. Do not attempt to roll the unit over objects.
The air inlet and outlet should be free of any obstructions and be placed with at least 20″ of clearance
for efficient air-conditioning and circulation.
Exhaust hose Installation
When using the air conditioner, the hot air from the exhaust hose must be exhausted out of the room
to complete the air exchange of the condenser. When the unit is operating in dehumidifying or fan-
only mode, installation of the exhaust hose is optional.
1. Fully expand each end of the exhaust hose about 6″.
2. Install the hose connectors onto the exhaust hose by threading counterclockwise.
3. Align the tab cut-outs on one of the hose connectors to the tabs on the air exhaust at the rear of
the unit and snap in place.
Only extend the hose to the necessary length, keeping it as short and as straight as possible. We do
not recommend extending the hose more than 9′ long. If you are interested in purchasing an
additional 5′ exhaust hose, please contact support@whynter.com for retail sales information or
visit whynter.com for a list of optional accessories.
Window kit Installation
The window kit has been designed to fit most standard vertical and horizontal windows. However, it
may be necessary to modify the installation procedures to accommodate your window.
If your window opening is smaller than the minimum length of the window slider kit, the window
slider kit can be cut to fit the window opening. Never cut into the exhaust hose cut-out on the
window slider kit.
If your window opening is larger than the maximum length of the window slider kit, additional
material will be needed to cover the open space such as, Plexiglas, PVC plastic, ply wood, etc.
Alternately, an additional window slider kit can be purchased to be used in combination with the
included kit.
