WHYTE Service Manual
8.0: TORQUE SETTINGS
Torque explained: If no suitable Torque Wrench is available a Torque of 5 lbf.ft can be obtained by apply-
ing a force of 5lb, with a Spring Balance, to the end of a spanner, 1 Foot in length.
IMPORTANT: For all other torque settings, refer to the specific manufacturers information
bundled with this manual, or alternatively, refer to the specific manufacturers website for
further information.
9.0: NOTES
Rear Quad-Link Suspension: Nm lbs.ft
Link Outer Bearing Caps 2.0 (Min) / 3.0 (Max) 1.5 (Min) / 2.2 (Max)
M8 AeroSpace Nuts 17.0 (Min) / 19.0 (Max) 12.5 (Min) / 14.0 (Max)
Rear Dropout Assembly
Chain ring Bolts (E-120 Dropout) 15.0 (Min) / 25.0 (Max) 11.0 (Min) / 25.0 (Max)
M6 cap-screws (T-120S or 146S Dropout) 10.5 (Min) / 12.5 (Max) 7.7 (Min) / 9.2 (Max)
M6 Countersunk Cap-screws (146 Y-link) 9.0 (Min) / 10.0 (Max) 6.6 (Min) / 7.4 (Max)
