WI-PMS310GF-Alien-I QSG Page 6 of 21
6. Top Panel
6.1 DC Inputs
LED Input Comment
V1 and V2 Nominal 48 V DC
(37 ~ 57 VDC)
8A max
One or both can be active, allowing
redundant power supplies.
V3 12 to 57 VDC
10A max.
An alternative to V2. Wide voltage range
suitable for unregulated solar panel input.
