WI-PMS310GF-Alien-I QSG Page 7 of 21
6.2 Alarm Connections
Alarm state is set based on both
• the IN+/IN- physical connection, and
• a number of software selectable internal triggers. See the
page.
Label Connection
IN+/IN- Monitoring of this input has these software selectable options:
• Close: No monitoring or action
• Low Level: Alarm is triggered if voltage below 5V, or
IN+/IN- are shorted together.
• High Level: Alarm is triggered if voltage above 5V
(max. 57V)
AL+/AL- This is a relay connection. Options are:
• Close: Always Closed
• Normally Closed: Open if Alarmed
• Normally Open: Closed if Alarmed
• Impulse: Repeated:
Closed 1 sec, Open 1 sec
6.3 Other
Label Connection
TMS Temperature & Humidity sensor. Use the supplied sensor.
Use is optional, but can be used as Alarm inputs.
RET To reset the Switch to factory defaults:
The Switch should be running after bootup is complete and
the PWR LED blinking. Press and hold the Reset button until
the PWR LED starts flashing rapidly. Release the Reset
button.
