Description of Product Chapter 1
30.08.19 Working Instructions WIDOS 4600 Page 8 of 32
Ambient conditions in the welding area: - Take care for cleanness (no dust at the welding
area)
- Do not weld below 5° C, if necessary preheat
- Avoid humidity, if necessary put up a tent
- Avoid strong sun rays influence
- Protect from wind, shut the pipe ends
1.5.1.2 Planer
Motor: Monophase-alternating current motor
Power: 1150 Watt
Voltage: 230 V ( 10 %)
Nominal current: 4.5 A
Frequency: 50 Hz ( 10 %)
Speed n1 of motor: 760 rpm
Speed n2 of planer: 60 - 100 rpm
Attached elements: On/off-switch with fixing device
Connecting cable and plug with earthing contact
Weight: appr. 14 kg
1.5.1.3 Heating Element
Power: 1500 Watt
Voltage: 230 V ( 10 %)
Current: 6.5 A ( 10 %)
Frequency: 50 Hz
Outside-: 320 mm
Surface: Nonstick coated
Elements: Electronic temperature control
Control lamps, on/off-switch
Connecting cable and plug with earthing contact
Weight: appr. 6 kg
