1.3. Safety Measures
In case of wrong use, wrong operation or wrong maintenance the machine itself or products standing
nearby can be damaged or destroyed.
Persons being in the endangered area may be injured.
Therefore these working instructions have to be thouroughly read and the corresponding safety
regulations must be necessarily adhered to.
1.4. Conformity
The machine corresponds in its construction to the valid recommendations of the European Community
as well as to the European standard specifications.
The development, manufacturing and mounting of the machine were made very carefully.
1.5. Designation of the Product
The product is designated by two type labels which are attached at the aggregate and at the basic
machine.
They contain the type, the serial number and the year of construction of the machine.
1.5.1 Technical Data
1.5.1.1 WIDOS 4600 General Data
Material: PP, PE 80, PVDF, PE 100
Pipe diameter range: outside- = 75 - 250 mm
Transport box (lxwxh):
Weight:
Cases with compartments for reduction
inserts:
4 compartments:
7 compartments:
9 compartments:
appr. 950 x 850 x 570 mm
appr. 40 kg
appr. 680 x 410 x 310 weight: appr. 10 kg
appr. 1160 x 410 x 310 weight: appr. 16 kg
appr. 1470 x 410 x 310 weight: appr. 21 kg
Packing box (lxwxh):
Weight:
appr. 1230 x 980 x 670 mm
appr. 67 kg
Weight (without boxes): appr. 93 kg
Fuse: 16 A
Wire cross section: 1.5 mm²
Emissions - The sound intensity level while using the planer is
appr. 86 dB (A).
- When using the named pipe materials and when
welding below 260° C no toxicant damp arises.
