Description of Product Chapter 1
30.08.19 Working Instructions WIDOS 4600 Page 9 of 32
1.5.1.4 Hydraulic Aggregate
Power: 0,3 kW
Voltage: 230 V ( 10 %)
Current: 2,7 A
Frequency: 50 Hz
Hydraulic oil tank: appr. 1 L
Electromotor and pump:
Speed: 1380 (rpm)
Max. working pressure of pump: appr. 120 bar
Working pressure: 100 bar
Volume velocity: 1.9 L/min
Weight : appr. 23 kg
1.5.1.5 Basic Frame
Dimensions (lxwxh): 800 x 420 x 460 mm
Reduction inserts: Dimensions can be selected
Material frame: Machinery steel
Material clamping shells: Aluminium
Weight: appr. 40 kg
cylinder: 35 mm
piston rod: 30 mm
Length of stroke of cylinder: 140 mm
Max. force: (F=P*A) 5200 N (at 100 bar)
Velocity of piston rod: 6.2 cm/s
See spare parts list for article numbers and single parts
1.6. Equipment and Accessories:
The following accessories are part of the first delivery:
1 Tool bag for 10 parts
1 Socket spanner size 27
1 Torx screw driver T10
1 each Allan key angulate, size 3 / 6 / 8
1 each Allan key with T grip size 4 / 5
optional Different sizes of reduction inserts, roller brackets for the pipes
