Spare parts list Chapter 10
Chapter 10Chapter 10
Chapter 10
Basic machine
Basic machineBasic machine
Basic machine
WIDOS MAXIPLAST
Pos.
Denomination
Piece
Order no.
44
Parallel pin 6m6x32 DIN 6325
2
6325F032
45
Parallel pin 6m6x16 DIN 6325
4
6325F016
46
Pan-head screw M 4 x 10 DIN 912
1
0912D010
47
Lock washer size 5 DIN 6799
2
6799E
48
Feather key 5x5x18 DIN 6885
1
6885E018
49
Washer 8,4 DIN 125
4
0125H
50
Washer 6,4 DIN 125
2
0125F
51
presuure piece
1
454009
52
Table support
1
454101
53
Stargrip Ø40-M8x30
4
on request
54
Covering cap Ø 12
4
on request
--
Reducer inserts, OD 50 - OD 140, two parts
2 set
1608...*
--
Reducer inserts large, OD 50 - OD 140, two parts
2 set
1618...*
--
Reducer inserts extra large OD 50 - OD 140, two parts
2 set
1628...*
--
Pan-head screw M5x16 DIN 912 (for OD 50 - 125)
8
0912E16X
--
Flat-head screw M5x16 DIN 7991 (for OD 140)
8
7991E16X
56
Pipe support, OD 50 - OD 160
2
0106...*
57
Knurled screw M 5 x16 DIN 464
2
0464E016
--
Type plate
1
SCHTMAXI
--
Allan key with T-grip size 3
1
ZIT03
--
Allan key with T-grip size 4
1
ZIT04
--
Allan key tilted size 5
1
ZIG05
* When ordering, please state the dimension of the diameter!
