Spare parts list Chapter 10
Chapter 10Chapter 10
Chapter 10
Planer
PlanerPlaner
Planer
WIDOS MAXIPLAST
Pos.
Denomination
Piece
Order no.
1
Bow grip (GN565.1-26-164-BL)
1
on request
2
Pan-head screw M6x20 DIN 912
2
0912F020
3
Disc milling cutter, left
1
454403
4
Disc milling cutter, right
1
454402
5
Blade
4
MES072
6
Flat-head screw M 3x6 DIN 965
12
0965C006
7
Planer disc bolt
1
450436
8
Ball bearing 6010 2RS
1
L60102RS
9
Adlusting ring
1
450437
10
Bevel gear
1
454409
11
O-ring 105 x 3
1
D105x3
12
Pan-head screw M8x25 DIN 6912
2
6912H025
13
Drilling machine MBF 13
1
AMBF13
14
Holder for planer
1
454401
15
Pinion
1
454408
16
Spindle for pinion
1
454431
17
Ball bearing 16101
2
L16101
18
Spacer
1
454412
19
Spacer
1
454413
20
Spacer ring
1
450444
21
Washer M 10 DIN 433
1
0433J
22
Hexagon nut M10x1 DIN 934
1
0934J1
23
Washer
1
450441
24
Coupling
1
454410
25
Pan-head screw M6x30 DIN 912
1
0912F030
26
Washer M6 DIN 125
1
0125F
27
Hexagon nut M6 DIN 985
1
0985F
28
Stargrip M8x40 DIN 6336
1
BG40KTK
29
Extension for planer detent
1
454414
30
Pan-head screw M8x20 DIN 6912
2
6912H020
31
Ball bearing 624 2Z
2
L0624ZZ
32
Washer M 4 DIN 125
4
0125D
33
Grooved pins Ø 4 x 1472
2
1472D020
34
Pressure spring B0,63x1,5x7,5
1
450409
35
Ball Ø4,5
1
L0005
36
Prevailing torque hexagon nut M 6 DIN 985
1
0985F006
37
Screw washer
1
450408
--
Torx-screwdriver T10
1
ZT10
