widos MAXIPLAST - Page 52

Spare parts list Chapter 10
Chapter 10Chapter 10
Chapter 10
Heating element
Heating elementHeating element
Heating element
WIDOS MAXIPLAST
Pos.
Denomination
Piece
Order no.
1
Anti-stick coated insulating washer
1
H09091
2
Switch on/off with control lamp (red)
1
H0903
3
Control knob with slot
1
H09075
4
Scale 180°-280° (d33)
1
H0908
5
Window cap for grip shell (white)
1
H09072
6
Control lamp (green)
1
H0905
7
Cylinder-head screw M 6x55 DIN 912
2
0912F055
8
Spring washer M6 DIN 127
2
0125F
9
Electronic control GZ4
1
H0918220
10
Temperature probe PT 1000
1
H09082
11
Isolator piece
1
454502
12
Heating element , complete
1
HMAXI
Heating plate new, electric
1
HPMAXI
Heating plate for change, electric
1
HPTMAXI
13
Heat sink with triac
1
H09081
14
Heating element holder
1
454503
15
Cylinder-head screw M 4x65 DIN 912
3
0912D065
16
Gripping form
2
012505
17
Grip shell
1
450504
18
Sheet metal screw C 4,8x16 DIN 7981
3
7981E016
19
Strain relief
1
H09076
20
Sheet metal screw C 2,9x13 DIN 7981
2
7981C013
21
Cable bushing
1
EKT08
22
Connection cable with plug
1
EK3220
230
Spring washer M4 DIN 127
3
0127D
