13WIKA operating instruction pressure transmitter, model A-10
EN
11218720.15 07/2018 EN/DE/FR/ES
Faults Causes Measures
No output signal Cable break Check the continuity
Deviating zero point signal Overload safety exceeded Observe the permissible overload safety
Deviating zero point signal Too high/low working temperature Observe the permissible temperatures
Constant output signal upon change in
pressure
Mechanical overload caused by overpres-
sure
Replace instrument; if it fails repeatedly,
contact the manufacturer
Signal span varies EMC interference sources in the environ-
ment; for example, frequency converter
Shield instrument; cable shield; remove
source of interference
Signal span varies/inaccurate Too high/low working temperature Observe the permissible temperatures
Signal span drops/too small Mechanical overload caused by overpres-
sure
Replace instrument; if it fails repeatedly,
contact the manufacturer
If complaint is unjustied, we will charge you the complaint processing fees.
6. Faults

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the WIKA A-10 and is the answer not in the manual?

WIKA A-10 Specifications

General IconGeneral
Ingress ProtectionIP65, IP67
MaterialStainless steel
Output Signal4 ... 20 mA, 0 ... 10 V, 0 ... 5 V, 1 ... 5 V
Accuracy≤ ±0.5 % of span
Process Connection1/4 NPT, 1/2 NPT
Electrical ConnectionM12 x 1
Supply Voltage12...30 V DC
