WIKA A-10 User Manual

18 WIKA operating instruction pressure transmitter, model A-10
EN
11218720.15 07/2018 EN/DE/FR/ES
Measuring ranges and overload safetys (absolute pressure)
bar Measuring range 0 ... 0.1 0 ... 0.16 0 ... 0.25 0 ... 0.4 0 ... 0.6 0 ... 1 0 ... 1.6
Overload safety 1 1 1 1 3 3 3.2
Measuring range 0 ... 2.5 0 ... 4 0 ... 6 0 ... 10 0 ... 16 0 ... 25
Overload safety 5 8 12 20 32 50
inWC Measuring range 0 ... 40 0 ... 60 0 ... 80 0 ... 100 0 ... 120 0 ... 150 0 ... 200
Overload safety 400 400 400 400 400 400 400
Measuring range 0 ... 250 0 ... 400
Overload safety 1,200 1,200
psi Measuring range 0 ... 5 0 ... 15 0 ... 25 0 ... 30 0 ... 50 0 ... 100 0 ... 150
Overload safety 14.5 45 60 60 100 200 290
Measuring range 0 ... 200 0 ... 300
Overload safety 400 600
Measuring ranges and overload safetys (vacuum and +/- measuring ranges)
bar Measuring range -0.025 ... +0.025 -0.05 ... 0 -0.05 ... +0.05 -0.05 ... +0.15 -0.05 ... +0.2
Overload safety ±0.2 ±0.2 ±0.2 1 1
Measuring range -0.05 ... +0.25 -0.1 ... 0 -0.1 ... +0.1 -0.15 ... +0.15 -0.16 ... 0
Overload safety 1 ±0.2 1 1 1
Measuring range -0.2 ... +0.2 -0.25 ... 0 -0.25 ... +0.25 -0.3 ... +0.3 -0.4 ... 0
Overload safety 1 1 1 3 1
Measuring range -0.5 ... +0.5 -0.6 ... 0 -1 ... 0 -1 ... +0.6 -1 ... +1.5
Overload safety 3 3 3 3.2 5
Measuring range -1 ... +3 -1 ... +5 -1 ... +9 -1 ... +15 -1 ... +24
Overload safety 8 12 20 32 50
9.Specications

WIKA A-10 Specifications

General

Ingress Protection	IP65, IP67
Material	Stainless steel
Output Signal	4 ... 20 mA, 0 ... 10 V, 0 ... 5 V, 1 ... 5 V
Accuracy	≤ ±0.5 % of span
Process Connection	1/4 NPT, 1/2 NPT
Electrical Connection	M12 x 1
Supply Voltage	12...30 V DC
