21WIKA operating instruction pressure transmitter, model A-10
EN
11218720.15 07/2018 EN/DE/FR/ES
Specications
Insulation voltage DC 500 V
Wetted parts Measuring range < 10 bar Stainless steel 316L
Measuring range ≥ 10 bar Stainless steel 316L and PH grade steel
Measuring range ≤ 0 ... 25 bar abs. Stainless steel 316L
Non-wetted parts Stainless steel 316L, HNBR, PA, cable from PUR
Pressure transmission medium Measuring range < 0 ... 10 bar gauge Synthetic oil
Measuring range ≤ 0 ... 25 bar absolute Synthetic oil
Measuring range ≥ 0 ... 10 bar gauge Dry measuring cell
For further specications see WIKA data sheet PE 81.60 and the order documentation.
9.Specications

WIKA A-10 Specifications

General

Ingress Protection	IP65, IP67
Material	Stainless steel
Output Signal	4 ... 20 mA, 0 ... 10 V, 0 ... 5 V, 1 ... 5 V
Accuracy	≤ ±0.5 % of span
Process Connection	1/4 NPT, 1/2 NPT
Electrical Connection	M12 x 1
Supply Voltage	12...30 V DC
