5.4 Mounting
5.4.1 Transmitter in head mounting version (model T15.H)
The transmitters for head mounting (model T15.H) are designed to be mounted on a
measuring insert within a form B, DIN connection head, with extended mounting space.
The connection wires of the measuring insert must be approx. 50 mm long and insulated.
Mounting in connection head
Insert the measuring insert with the mounted transmitter into the protective fitting and
secure into the connection head using screws in pressure springs.
Installing with DIN rail adapter
With the mechanical adapter, available as an accessory, the T15.H head-mounted
transmitters can also be fixed on a DIN rail.
5.4.2 Transmitter in rail mounting version (model T15.R)
Fasten the rail mounting case (model T15.R) onto a 35 mm DIN rail (EN 60175) by simply
locking it into place without the need for any tools.
Disassembly involves unlocking the detent element.
Mounting example
14139114.01
14139114.01
