14139245.01 12/2015 EN/DE
WIKA operating instructions model T15 27
10. Specifications
DANGER!
Danger to life due to loss of explosion protection
The non-observance of the instructions for use in hazardous areas can lead
to the loss of the explosion protection.
▶
Adhere to the following limit values and instructions.
Specifications Model T15
Permissible ambient temperature range {-50} -40 ... +85 {+105} °C
{-58} -40 ... +185 {+221} °F
Climate class per IEC 654-1:1993 Cx (-40 ... +85 °C, 5 ... 95 % r. h.)
Maximum permissible humidity
■
Model T15.H
per IEC 60068-2-38:2009
■
Model T15.R
per IEC 60068-2-30:2005
Test max. temperature variation 65 °C / -10 °C,
93 % ±3 % r. h.
Test max. temperature 55 °C, 95 % r. h.
Vibration resistance
per IEC 60068-2-6:2008
Test Fc: 10 ... 2,000 Hz; 10 g, amplitude 0.75 mm
Shock resistance
per IEC 68-2-27:2009
Acceleration / shock width
30 g / 11 ms
100 g / 6 ms
Salt fog
per IEC68-2-52:1996, IEC 60068-2-52:1996
Severity level 1
Condensation Model T15.H: acceptable
Model T15.R: not acceptable
Free fall
in line with IEC 60721-3-2:1997,
DIN EN 60721-3-2:1998
Drop height 1.5 m
Electromagnetic compatibility (EMC)
per DIN EN 55011:2010, DIN EN 61326-2-3:2013,
NAMUR NE21:2012, GL 2012 VI part 7
2004/108/EC, EN 61326
Emission (group 1, class B) and interference
immunity (industrial application)
[HF field, HF cable, ESD, Burst, Surge]
{ } Items in curved brackets are options for an additional price, not for ATEX versions of the head mounting version and not for
T15.R rail mounting version
In the event of interference caused by high-frequency electromagnetic fields in a frequency
range from 80 to 400 MHz, an increased measuring deviation of up to 0,8 % is expected.
During transient interferences (e.g. burst, surge, ESD) take into account an increased
measuring deviation of up to 1,5 %.
