Wilden P800 - Wilden Pump Designation System

WILDEN PUMP & ENGINEERING, LLC 2 WIL-11250-E-03
P800/PX800 PLASTIC
51 mm (2") Pump
Maximum Flow Rate:
693 lpm (183 gpm)
LEGEND
PX800 / XXXXX / XXX / XX / XXX / XXXX
O-RINGS
MODEL
VALVE SEAT
VALVE BALLS
DIAPHRAGMS
AIR VALVE
CENTER BLOCK
AIR CHAMBERS
WETTED PARTS & OUTER PISTON
SPECIALTY
CODE
(if applicable)
MATERIAL CODES
MODEL
P800 = PRO-FLO
®
PX800 = PRO-FLO X™
WETTED PARTS
KK = PVDF / PVDF
PK = POLYPROPYLENE / PVDF
AIR CHAMBERS
P = POLYPROPYLENE
CENTER BLOCK
P = POLYPROPYLENE
AIR VALVE
P = POLYPROPYLENE
L = ACETAL (P800 only)
DIAPHRAGMS
BNS = BUNA-N (Red Dot)
BNU = BUNA-N, ULTRA-FLEX™
EPS = EPDM (Blue Dot)
EPU = EPDM, ULTRA-FLEX™
FSS = SANIFLEX™
[Hytrel
®
(Cream)]
NES = NEOPRENE (Green Dot)
NEU = NEOPRENE, ULTRA-FLEX™
PUS = POLYURETHANE (Clear)
TEU = PTFE W/EPDM
BACK-UP (White)
TNU = PTFE W/NEOPRENE
BACK-UP (White)
TSU = PTFE W/SANIFLEX™
BACK-UP (White)
VTS = VITON
®
(White Dot)
VTU = VITON
®
, ULTRA-FLEX™
WFS = WIL-FLEX™ [Santoprene
®
(Orange Dot)]
TSS = FULL STROKE PTFE
W/SANIFLEX™ BACK-UP
TWS = FULL STROKE PTFE
W/WIL-FLEX™ BACK-UP
VALVE BALL
BN = BUNA-N (Red Dot)
EP = EPDM (Blue Dot)
FS = SANIFLEX™
[Hytrel
®
(Cream)]
NE = NEOPRENE (Green Dot)
PU = POLYURETHANE (Clear)
TF = PTFE (White)
VT = VITON
®
(White Dot)
WF = WIL-FLEX™ [Santoprene
®
(Orange Dot)]
VALVE SEAT
K = PVDF
P = POLYPROPYLENE
VALVE SEAT & FLANGE O-RING
BN = BUNA-N
TV = PTFE ENCAP. VITON
®
W F = W IL-F LE X ™ ( Santoprene)
Section 2
WILDEN PUMP DESIGNATION SYSTEM
SPECIALTY CODES
0100 Wil-Gard 110V
0102 Wil-Gard sensor wires ONLY
0103 Wil-Gard 220V
0206 PFA coated hardware,
Wil-Gard II™ sensor wires ONLY
0480 Pump Cycle Monitor (sensor & wires)
0483 Pump Cycle Monitor (module, sensor & wires)
0485 Pump Cycle Monitor (module, sensor & wires),
DIN flange
0502 PFA Coated
0504 DIN Flange
0506 DIN Flange, PFA Coated
0513 SS outer pistons
0604 DIN flange Wil-Gard II™
0608 PFA coated hardware, Wil-Gard II™ 220V
0690 Center-Ported ANSI/DIN Combo
0691 Center-ported, ANSI/DIN combo flange, PFA
coated fasteners
0733 Center-ported, Reversed ANSI/DIN combo
flange (inlet facing air inlet/discharge facing
exhaust)
0734 Center-ported, Reversed ANSI/DIN combo
flange (inlet facing air inlet/discharge facing
exhaust), PFA coated fasteners
NOTE: MOST ELASTOMERIC MATERIALS USE COLORED DOTS FOR IDENTIFICATION.
NOTE: Not all models are available with all material options.
Viton
®
is a registered trademark of DuPont Dow Elastomers.
