24
FM +
Audio Level Indicators
10-LED array that reads -18 to +9 dB at 3 dB intervals. 7 Green, 2 Amber, and 1 red LED. Green LEDs
indicate normal operating audio level peaks, Amber LEDS indicate close to overload peaks, Red LED
indicates overload peaks
Headphone Output
1/4” TRS stereo jack, mono signal, 14.85 mW at +9 dB, maximum in 33 Ω (level adjustable in menu 0 to -40
dB in 2 dB steps)
Line Output
RCA jack (black), -10 dBV (.32 VRMS); Output impedance 100 Ω at +9 dB
Input Levels (Bal or Unbal)
(at Audio Input Gain = 0dB)
Nominal (1st Amber LED)
Overload Warning
(Displayed On Screen)
Absolute Max. Rating*
Microphone
-55 dBV (1.7 mV RMS) -22 dBV (80 mV RMS) +20 dBV (10.0 V RMS)
Line
-25 dBV (55 mV RMS) +16 dBV (6.3 V RMS) +20 dBV (10.0 V RMS)
Approvals
FCC, RoHS3, WEEE, Industry Canada
Warranty
2-year parts and labor
NOTE: SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE
**
Stresses above these ratings may cause permanent damage. Exposure for extended periods may degrade reliability.
This device complies with Industry Canada licence-exempt RSS standard(s) and FCC part 15.105[b] for the United States.
Operation is subject to the following two conditions: [1] this device may not cause interference, and [2] this device must accept any interference,
including interference that may cause undesired operation of the device.
