Wilo Atmos PICO User Manual

Fig. 1:
9
8
7
10
1 11
4
5
2
3
6
Fig. 2: Fig. 3a:
Fig. 3b:
PE
N
L

Wilo Atmos PICO Specifications

General

Max Flow Rate	2.5 m³/h
Max Head	6 m
Protection Class	IP42
Insulation Class	F
Maximum Operating Pressure	10 bar
Voltage	230 V
Frequency	50 Hz
Connection Size	1 inch
Type	Circulation Pump
Application	Domestic Hot Water Circulation
Max Liquid Temperature	95°C
Weight	2.1 kg
