6 Installation and electrical con-
nection
6.1 Installation types
WARNING
Risk of personal injury!
• Adhere to existing accident prevention regulations.
Installation on base frame, FM (frame mounted)
For compact pressure-boosting systems, the control device (depending on the system
series) can be mounted on the base frame of the compact unit with 5 screws (M10).
Floor model, BM (base mounted)
The control device is set up free-standing on a level surface (with sufficient load-bearing
capacity). In the standard version, there is an up-right panel support (height 100mm) for
the cable inlet. Other supports are available on request.
Wall fixation, WM (wall mounted)
In compact pressure-boosting systems, the control device (depending on the system
series) can be mounted on a mounting bracket with 4 screws (M8).
6.2 Electrical connection
DANGER
Risk of fatal injury due to electrical current!
Improper conduct when carrying out electrical work can lead to death
due to electric shock!
• Electrical work must be carried out by a qualified electrician in accord-
ance with the locally applicable regulations.
• If the product is disconnected from the mains, secure it against being
switched on again.
NOTICE
All cables to be connected must be inserted through threaded cable
glands (FM and WM installation type) or cable inlet plates (BM installation
type) into the control device and secured so that they are not under ten-
sion.
