Maintenance
E:\shares\Baprod\BA\subtec_m\sew
age\us\fkt27\maintenance.fm
7-11
M6
7.
5
0.76
M20
230.0
23
.45
M8
18.5
1.89
M24
285.0
29.05
M10
37
.0
3.77
M27
415.0
42.30
M12
57
.0
5.81
M30
565.0
57
.59
Thre
ad
Nm
kp m
Thread
Nm
kp m
T
able
7-4
: R
ust
proo
f s
crew
s wi
th
out
Nord
-Lo
ck
scre
w fi
xi
ng
46
48
Table of Contents
Table of Contents
3
Illustrations
7
Manufacturer's Address
9
Rights of Alteration
9
Safety
11
Instructions and Safety Information
11
Guidelines Used and CE Certification
12
General Safety
12
Electrical Work
12
Electrical Connection
13
Ground Connection
13
Operating Procedure
13
Safety and Control Devices
13
Operation in an Explosive Atmosphere
14
Sound Pressure
14
Pumped Fluids
14
Warranty
15
Product Description
17
Proper Use and Fields of Application
17
Conditions of Use
17
Construction
17
Type Designation
20
Cooling
20
Name Plate
21
Technical Data
21
Transport and Storage
25
Delivery
25
Transport
25
Storage
25
Returning to the Supplier
26
Installation
27
General Information
27
Installation Types
27
The Operating Area
27
Assembly Accessories
27
Dry-Run Protection
32
Removal
32
Startup
33
Preparatory Measures
33
Electrical System
33
Direction of Rotation
34
Motor Protection and Activation Types
34
After Starting
35
Maintenance
37
Lubricants
38
Maintenance Intervals
39
Maintenance Tasks
40
Sealing Chamber
41
Repairs
44
Torque Values
46
Shutdown
49
Temporary Shutdown
49
Final Shutdown / Storage
49
Restarting after an Extended Period of Storage
49
Troubleshooting
51
Fault: the Machine will Not Start
51
Fault: the Motor Starts, but the Motor Protection Switch Triggers Shortly after Start-Up
51
Fault: Machine Runs but Does Not Pump
52
Fault: the Machine Runs, but Not at the Stated Operating Levels
52
Fault: the Machine Does Not Run Smoothly and Is Noisy
53
Fault: Mechanical Shaft Seal Leaks, Sealing Chamber Monitor Reports Fault and Switches the Machine off
53
Further Steps for Troubleshooting
54
A List of Machine Operators and Maintenance
55
List of Machine Operators
55
Assembly Sheet for the Anchor Bolts
59
General Product Information
59
Scope of Proper Use
59
Transport and Storage
59
Setting the Anchor Bolts
59
Operation with a Static Frequency Converter
65
Selecting the Motor and Converter
65
Minimum Speed for Submersible Pumps
65
(Well Pumps
65
Minimum Speed for Waste Water and Sewage Pumps
65
Operation
65
Max. Voltage Peaks and Rise Speed
65
Emc
66
Motor Protection
66
Operation up to 60 Hz
66
Efficiency
66
Summary
66
E Ceram C0 Data Sheet
67
General Information
67
Description
67
Composition
67
Properties
67
Technical Data
67
Resistance
68
Surface Preparation
69
Material Preparation
69
Application Instructions
69
Coating Layers and Material Requirements
69
Repeat Coating Intervals / Subsequent Coating
69
Hardening Time
69
Material Needed
70
Working Steps
70
Cleaning Tools
70
Storage
70
Safety Precautions
70
F Notes on Unloading Large Units
71
Data Sheet - Electrical Connection
73
Safety Notes
73
Insulation Resistance
73
Monitoring Equipment
73
Wire Designation of the Connection Lead
74
HEC Declaration of Conformity
77
