Assembly Sheet For the Anchor Bolts
E:\shares\Baprod\BA\subtec_m\appendix\us\general\anchor_bolts.fm C-1
C Assembly Sheet For the Anchor Bolts
General product infor-
mation
Anchor bolts consist of a metal anchor rod, a grout cartridge (a glass tube or plastic bag containing
adhesive cement), a washer and a hexagonal nut. They create a firm connection in concrete foun-
dations, thus enabling heavy loads to be supported. Once fitted, the anchor cannot be removed!
Scope of proper use
The anchor bolts supplied by WILO EMU GmbH may only be used for WILO auxiliary hoisting gear
and accessories.
These anchor bolts may only be used in normal reinforced or non-reinforced concrete in a strength
class of min. C20/25 and max. C50/60 (according to EN 206:2000-12). The foundation for the
anchors should be dry. The anchor bolt is only suitable for non-cracked concrete. Anchor bolts are
also available for cracked concrete.
Before using the anchor bolts, make sure the background structure is strong enough to withstand
the reactive forces generated by the auxiliary hoisting gears and their accessories.
The anchor bolts are designed to fasten auxiliary hoisting gears and their accessories to the basis
edge and/or basin floor.
Transport and storage
Take care not to damage the grout cartridge during transport, as otherwise the adhesive cement
will harden. Do not use faulty grout cartridges. Do not use grout cartridges after the expiration date
printed on them.
The cartridges must by transported only at temperatures between -5°C and 30°C and stored at
temperatures between 5°C to 25°C. The mortar cartridge must be kept in a cool, dry, dark place.
Setting the anchor bolts
Beware of irritant substances!
The grout cartridges contain dibenzoyl peroxide. This substance is
caustic. Note the following information:
R36/38 Irritates eyes and skin
R43 Skin may react to contact
S37/39 Wear suitable protective clothing during work
S26 If it comes into contact with the eyes, wash them out with
water and call a doctor
S28 If it comes into contact with the skin, wash thoroughly with
water and plenty of soap
Name Rod length
Drill hole
depth
Drill hole
diameter
Min. distance
from edge a
r
HAS-R M8x80/14 110mm 80mm 10mm 100mm
HAS-R M12x110/28 160mm 110mm 14mm 135mm
HAS-R M16x125/38 190mm 125mm 18mm 155mm
HAS-R M16x125/108 260mm 125mm 18mm 155mm
HAS-E-R M20x170/48 240mm 170mm 24mm 210mm
HAS-E-R M24x210/54 290mm 210mm 28mm 260mm
Table C-1: Dimensions and tightening torque values
