BAIARDO L OPERATION MANUAL BAIARDO L OPERATION MANUAL
1 2
Congratulations on purchasing the Wilson Baiardo L
stringing machine.
Built upon the architecture and design of the award-winning Wilson Baiardo
machine, the Baiardo L oers a simpler, more lightweight option for stringers
to use worldwide. Top features include:
• 20% lighter than original Wilson Baiardo
• Manual height and tilt adjustment for practical ergonomic design and comfort
• Mounting posts adjust inward to better accommodate badminton racquets
• Five-teeth clamps to maximize grip while minimizing string interference
• Reel rack on oor stand holds string reels for added convenience
This manual provides basic information about assembling and using your Baiardo
machine. All directions (right, left, front, back, etc.) are given from the stringer’s
perspective during stringing. The assumption is made that the user has strung
racquets and understands the basic operation of a stringing machine.
Further information can be found at www.wilson.com/baiardo.
Sincerely,
Baiardo Development Team
BAIARDO L
WARNINGS & PRECAUTIONS ............................3
ASSEMBLING THE MACHINE ............................3
DESCRIPTION OF PARTS ...............................4
DESCRIPTION OF PARTS BADMINTON ...................4
START UP. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
POWER UP ............................................ 5
BASICS ...............................................6
CLAMPS AND CLAMP BASES ...........................7
TURNTABLE BRAKE ....................................8
ADJUSTING THE PULLER HEAD .........................8
MACHINE HEIGHT ADJUSTMENT ........................9
FRICTION BRAKE ......................................9
TILT ADJUSTMENT ...................................10
DISPLAY INTERFACE .................................. 11
MAINTENANCE .......................................16
SERVICE ............................................. 17
TROUBLESHOOTING ..................................19
WARRANTY INFORMATION ............................21
BAIARDO L SPECIFICATIONS ...........................22

Wilson Electronics BAIARDO L Specifications

Power

power supply	External switching, 100-240 volts (60 watts)

Materials and Accessories

main material	Aluminum (25% recycled)
included stringing tools	Starter clamp, Needle nose pliers, Cutter, Awl
included assembly tools	All necessary hex keys

Weight and Dimensions

assembled weight	43.6 kg / 96.2 lb
width	104 cm / 41 in
height at maximum extension	130.4 cm / 51.3 in
height at minimum extension	100.4 cm / 39.5 in
machine top box size	L118.5 x W53.5 x H50 cm / L46.5 x W21 x H19.5 in
machine top box weight	44.7 kg / 98.5 lb
machine base box size	L82 x W57.5 x H30 cm / L32.5 x W22.5 x H12 in
