BAIARDO L OPERATION MANUAL
BAIARDO L OPERATION MANUAL
11 12
DISPLAY INTERFACE
KG/LBS
Toggle between LB and KG by pressing weight button
for 3 seconds. The delay is to avoid LB/KG by accident.
The display will now show the alternative unit of weight,
as indicated by the LED light under LB or KG.
KG LB
PULLER SPEED
Select any of 3 pulling speeds by touching the speed icon
and toggling between speeds.
SLOW MEDIUM FAST
OFF 10% 20%
PRESTRETCH
Adjust the amount of pre-stretch by a percentage.
Touch icon to toggle between 0%, 10% and 20%.
OFF ON
SOUND
Turn buzzer sound on or o by touching the sound icon.
The LED light under the sound button lights up while
the sound is turned on.
DIGITAL DISPLAY
ON
KNOT TENSIONING
Touch the knot button to tie o with 10% extra tension. After
touching the knot button, display will show the 10% extra
tension to be pulled.
The LED light under the knot button lights up until the string
is tensioned. This function works for a single time only.
TENSION DISPLAY
Set tension with Up / Down buttons.
Tension change is in increments of 0.5 LB or 0.5 KG.
Press the button longer to increase scrolling speed.
OTHER SETTINGS
Hold settings button for 3 seconds to bring up various
other settings for the machine. To go to next setting,
touch the UP button once. Quit settings at any time
by touching BACK button.
There are 6 functions of other settings:
• F1: Calibrate machine
• F2: Reset to default factory calibration
• F3: Reserved for future use
• F4: Adjust sensitivity of all touch buttons
• F5: Display quantity of rackets strung
• F6: Exit the settings
7.1 OPERATING THE
MACHINE
UP
DOWN
SETTING BACK ENTER
To select setting,
press ENTER button
DIGITAL DISPLAY
UP
DOWN
