Antenna Specifications
Part Number 301135 301147 301155
Frequency Range
700-800 MHz / 824-894 MHz / 880-960 MHz /
1710-1880 MHz
1850-1900 MHz / 2110-2170 MHz
Impedance 50 ohms 75 ohm
Gain
5.2 dBi 700-800 MHz / 4.4 dBi 824-894 MHz /
4.2 dBi 880-960 MHz /
10.1 dBi 1710-1880 MHz / 10.6 dBi 1850-1990 MHz /
8.2 dBi 2110-2170 MHz
Polarization Vertical
Beamwidth Horizontal Plane 70 / 60 Deg
Beamwidth Vertical Plane 50 / 45 Deg
Max Power 50 watts
Connector N-Female F-Female
Dimension 8.70 x 7.00 x 1.80 (inch) / 22.098 x 17.78 x 4.572 (cm)
Weight 1.32 lbs / 0.6 kg
3301 East Deseret Drive, St. George, UT 84790
For additional Technical Support visit www.WilsonElectronics.com
or email at: tech@wilsonelectronics.com
Phone: 866-294-1660 Local: 435-673-5021 Fax: 435-656-2432
www.twitter.com/WilsonCellular www.facebook.com/WilsonCellular
