5 OPM-171/B
SPECIFICATIONS
DE4040F4
MODEL DE4040F4-3 DE4040F4-4 DE4040F4-17 DE4040F4-18 DE4040F4-21
GENERATOR
Watts 40,000 40,000 40,000 40,000 40,000
Volts 120/240 120/208 120/240 277/480 346/600
Phase Single Three Three Three Three
PF 1.0 0.8 0.8 0.8 0.8
Amps 166 139 120 60 48
Hertz 60 60 60 60 60
ENGINE
Model FPT F5 C
Starting System 12 Volt
Fuel Consumption (full load) 4.16 Gal/hr
Fuel ASTM D-975 - 2D*
Oil Type See Lubrication section in this manual
Oil Capacity 10 Quarts
Cooling System 50/50 mix
* See engine manual for additional fuel types and specifications
COMPRESSOR ROTORCOMP NK 31 CAS R3
Max Operating Pressure 218 PSI (15 bar) 218 PSI (15 bar)
Oil Capacity 3.17 qts 3.17 qts
GENERATOR RESISTANCE (all value at 22°C)
Model Stamford UCI224C
Winding Group 311
Rotor 0.59 Ω
Stator 0.181 Ω
Exciter Rotor 0.071 Ω per phase
Exciter Stator 21 Ω
