86317500 CHARIOT SCRUBBER 71
Pedal Platform
REF PART NO. PRV NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTE
1 86008680 80607 1 COTTER, 1/2" RING
2 86274690 70258 2 SCR, 5/16-18 X 1.5 HHCS GR5PLT
3 86264920 27049 3 CABLE TIE, 7" UL/CSA
4 86231070 730328 2 BUMPER, 1 X 1.375 RUBBER
5 86010670 87029 3 WASHER, 5/16 FLAT SS
6 86259430 87485 4 M12 FLAT WASHER
7 86010770 87143 2 WASHER, 7/16ID X1D.08 FLT SS
8 86270830 57023 4 NUT, 5/16-18 HEX NYLOCK SS
9 86256470 70852 2 STUB AXLE, M12-1.75 X 45MM
10 86278850 80613 2 WASHER, .506 ID X .94D X .064 NYL
11 86248920 66487 1 PIN, CLEVIS 1/2 X 2.25
12 86064480 629993 1 PLATE, SWITCH BASE
13 86271190 57142 2 NUT, M12 X 1.75 HEX DIN934 PLT
14 86007780 73576 1 SPRING, COMP .60D X2.0L X .045W
15 86259440 87486 2 WASHER, M12 SPRING LOCK
To Next Page
