86317500 CHARIOT SCRUBBER 99
Squeegee Lift-Disk
REF PART NO. PRV NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES
1 86068190 140793 1 BRACKET, ACTUATOR MOUNT *(2) WAS 86315270
2 86273820 70019 1 SCR, 1/4-20 X 1.25 HHCS
3 86316550 - 1 ACTUATOR, 36VDC, 4.5:” STROKE
4 86083490 66831 1 PLATE, PULLEY MOUNT, CORNER
5 86068230 140840 1
BRACKET, SQG LIFT PULLEY
MOUNT
6 86270870 57029 3 NUT, 1/4-28 HEX SS
7 86002780 270098 1 CABLE, SQUEEGEE LIFT DELUXE
8 86277410 70840 4 SCR, 5/16-18 X 5/8 CARRIAGE SS
9 86075430 270700 1 COVER, SQUEEGEE LIFT
10 86270830 57023 9 NUT, 5/16-18 HEX NYLOCK SS
11 86276070 70593 3 SCR, 5/16-18 X 3/4 CARRIAGE SS
12 86277400 70839 2 SCR, 5/16-8 X 1.75 BSHCS SS
13 86010670 87029 10 WASHER, 5/16 FLAT SS
14 86277460 70847 1 SCR, 5/16-18 X 5/8 BSHCS SS
15 86271870 57290 2 NUT, 1/4-20 HEX NYLOCK THIN SS
16 86223370 66464 6 PULLEY, PLASTIC 3.0 DIA
17 86231150 09151 5 BUSHING, FLANGE, .314ID X .502OD
18 86083440 66824 1
PLATE, PULLEY MOUNTING,
CENTER
19 86276760 70724 2 SCR, 5/16-18 X 1.25 BSHCS SS
20 86274720 70264 2 SCR, 5/16-18 X 1.50 HHCS SS
21 86071300 140843 1
BRACKET, PULLEY RETAINER,
DOUBLE
22 86224290 730008 2 SPACER, .317ID X .5OD X .44 LG
23 86071310 140844 1 BRKT, PULLEY RETAINER, DOUBLE
24 86083500 66832 1 PLATE, PULLEY RETAINER, CORNER
25 86271840 57285 1 NUT, 5/16-18 HEX NYLOCK THIN SS
26 86228880 09132 1 BEARING, .314 ID X .503 OD X 1
27 86277480 70850 2 SCR, 5/16-18 X 1/2 PTHMS SS
To Next Page
