86317500 CHARIOT SCRUBBER 103
Squeegee Lift Assembly -Cylindrical - From Serial Number *(4)
* See serial number page.
**See Manufacturer for Serial Number.
REF PART NO. PRV NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES
1 86334910 - 2 SPRING, COMP, .480OD X 2.75L
2 86334760 - 1 SHAFT, SPRING
3 86333860 - 2 BRACKET, SPRING
4 86333590 - 1 BRACKET, MOUNT
5 86333580 - 1 BRACKET, LINK, PIVOT
6 86333570 - 1 BRACKET, LINK, LEFT
7 86333560 - 1 BRACKET, LINK, RIGHT
8 86333530 - 1 BRACKET, SQUEEGEE MOUNT
9 86259420 87232 4 WASHER, THRUST.51 ID X 1 ODBRO
10 86259400 87205 4 WASHER, THRUST .51 ID X 1 ODBRO
11 86010670 87029 9 WASHER, 5/16 X 3/4 SS
12 86010630 87013 5 WASHER, 1/4 X 5/8 FLAT SS
13 86278910 87003 2 WASHER, 3/8 X 7/8 FLAT SS
14 86005670 80606 2 COTTER, 3/8 RING
15 86277130 70795 6 SCR, 5/16-18X1.00 CARRIAGE SS
16 86276960 70773 1 SCR, 1/4-20 X 1.00 CARRIAGE SS
17 86276950 70772 4 SCR, 1/4-20 X 3/4 CARRIAGE SS
18 86005810 57245 5 NUT, 1/4-20 HEX NYLOCK SS
19 86270830 57023 6 NUT, 5/16-18 HEX NYLOCK SS
20 86228990 09153 6 BEARING FLG .314IDX.502OD
