86317500 CHARIOT SCRUBBER 111
Tank
REF PART NO. PRV NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES
1 86313100 - 1 DOME, TANK, 20 X 21
2 86310190 - 1 BASKET, STRAINER, DOME
3 86327510 - 6 SCR, KA50 X 16, WN1412 A2 SS
4 86290540 - 4 SCR, 10-32 X 1/2 TORX SS BLK NP
5 86315530 - 1 COLLAR, BAG
6 86025200 31377 1 ELBOW ASM, FLOAT
7 86199840 090-12A 1 FLOAT SCREEN CAGE ASSY (SLIP)
8 86294250 - 4 WASHER, .19ID X .5 X .09 THK BLK
9 86317770 - 1 GASKET, DOME
10 86315550 - 1 FRAME, BAG
11 86314160 - 1 FILL PORT LID
12 86275800 70546 6 SCREW 8 X3/4 PFHT/S BLK ZINC
13 86317620 - 1 RIM FILL PORT 4"BLACK W/O-RING
14 86312050 - 1 TANK, BLUE TRIM
15 86279630 87212 4 WASHER, .344IDX1.13ODX.09T PLT
16 86276490 70670 4 SCR, 5/16-18 X 5/8 HHCS GR5
17 86328980 - 1 CAP, DRAIN HOSE
18 86315500 - 1 HOSE, 2 X 30 DRAIN
19 86314080 - 1 NUT, DRAIN FITTING
20 86317360 - 1 GASKET, TANK DRAIN
21 86314070 - 1 FITTING, DRAIN
22 86317370 - 1 GASKET ASSY, DRAIN PLUG
23 86256100 730333 1 STRAINER, 3/4-MPT, 12 MESH
24 86314050 - 1 PLUG, DRAIN
25 86246080 51368 1 LANYARD, 18.0 W/LOOP & EYE
26 86312800 - 1 BAG RECOVERY
27 86317610 - 1 GASKET, 5.5 OD X4.5ID X.06W/PSA
28 86002390 20063 1 CLAMP, 1.75” WORM GEAR X .312”
29 86002380 20046 1 CLAMP, 2.25 WORM GEAR
30 86033570 78934 1 TUBE ASM
31 86003010 27759 1 CUFF, HOSE 1.5" BLK A 2161
32 86264950 27746 2 CABLE TIE, .19W X 11.5 L BLK
33A 86305960 - 1 HOSE ASM, 1.5 BLK PVC VAC X 67 DISK
33B 86318090 - 1 HOSE ASM, W/90 DEGREE METRIC CYLINDRICAL
