13786317500 CHARIOT SCRUBBER
Hose Diagram-Cylindrical
SHUT-OFF
PRV 39541
86281950 (32")
86280910 (23")
TANK
VALVE
DRAIN HOSE
STRAINER (FINE)
STARINER (COARSE)
86281950 (32")
PUMP
63908920
QUICK DISCONNECT
SOLENOID VALVE
86281100 (7")
PRV 39274
PRV 39541
